This wiki tries to provide information about the TomTom GO family, a linux-running all-in-one car navigation system. Please make sure to read the OpenTom:General disclaimer, in particular the paragraph about no warranty and no liability.

1 News
- 1.1 10th of January 2008: TomTom Console
2 Product Family
3 Frequently asked questions
4 Technical Information
- 4.1 Hardware
- 4.2 Software
  - 4.2.1 The TomTom Software, as published by TomTom B.V.
  - 4.2.2 The OpenTom Software
5 Miscellaneous, notes, hints, tips etc
6 Feedback
7 Contact

[edit]

News

[edit]

10th of January 2008: TomTom Console

The latest project is the TomTom Console. It works (at least) on the TomTom ONE V3 and openes the possibility to use thousands of console applications. Two popular examples are the editor pico and the mp3-player madplay. A project which is nearly fully ported is X11-Basic. The BASIC interpreter with graphics support. Last but not least, xearth has a revival on the TomTom.

Product Family

The TomTom family consists of:

TomTom GO (Classic)
- TomTom GO 300
- TomTom GO 500
- TomTom GO 510
- TomTom GO 520
- TomTom GO 520T
- TomTom GO 700
- TomTom GO 710
- TomTom GO 720
- TomTom GO 720T
- TomTom GO 910
- TomTom GO 920
- TomTom GO 920T
- TomTom GO Docking Stations

TomTom ONE
- TomTom ONE 1st Edition
- TomTom ONE 2nd Edition Europe / Regional
- TomTom ONE 3rd Edition Europe / Regional
- TomTom ONE XL Europe / Regional
TomTom Rider
- TomTom RIDER 2nd edition - Regional
- TomTom RIDER 2nd edition - Europe
Other
- TomTom Eclipse (AVN2227p, AVN2210p, AVN2210 Mk II)
- TomTom TOYOTA (TNS400)
- TomTom DAIHATSU

TomTom WORK
- TomTom Link
- TomTom Link 300 *NEW*

[edit]

Frequently asked questions

If you are looking for product specific information, click on your product model at the top of this page. For common Q&A go to Questions and Answers

[edit]

Technical Information

[edit]

Hardware

TomTom ONE 3rd Edition
Hardware Comparison
Preliminary IO map for TomTom Linux
The TomTom Classic Hardware

 * The Microcontroller (CPU)
 * The Memory (RAM)
 * The Connectors in general, including some preliminary info about TomTom 910
 * The Framebuffer
 * The Serial Console
 * The GPS unit
 * The Accelerometer
 * The Sound chip
 * The Watchdog
 * The Battery and power management
 * The TFT LCD Display
 * The Real Time Clock in hardware
 * The Touch Screen
 * Universal Serial Bus - client and host modes
 * General Purpose Input/Output
 * Bluetooth?
 * The TMC RDS receiver
 * The Photo Sensor

Other Hardware Stuff, mostly custom connectors

 * RS232 Bi-directional level shifter
 * A Docking station and homemade plugs
 * Another docking station.... using two car docking stations
 * TomTom GO 300 dismantled

[edit]

Software

[edit]

The TomTom Software, as published by TomTom B.V.

The Tomtom navigation software is closed source. But it required some software under GPL to be installed, and their sources have been published at http://www.tomtom.com/page.php?Page=gpl
Release dates and differences between TomTom Versions and Map Versions.
The ttsystem images and the boot process
The hello world example some info on the available functions
...

For a complete list check this: OpenTom:Community Portal

[edit]

The OpenTom Software

There are two types of software connected with Tomtom devices:

Software that runs on a desktop computer and feeds data to/analyses data from the device (e.g. Tomtom HOME). To create such Software, simply check out the file formats used by the embedded software, take your favourite programming environment and get started.
Software that runs on the device (e.g. Tomtom Navigation aka TTN). To create such software, you need to install a tool chain to develop software running on the ARM processor and linux operating system.

To quickly find out what has already been created, check the OpenTom:Community Portal
